Arduino, a board used for creating computers that can interact with the environment, senses various data using sensors and control devices such as lights and monitors. As an open-source platform based on microcontrollers, Arduino boards, including design files and CAD files, are available for users to modify as needed. Arduino was designed to provide a simple, affordable way for students and professionals to create microcontroller computers able to interact with the physical environment.
With its easy-to-use design and low cost, Arduino is popular among makers and hobbyists in the development environment. Arduino has two main segments: a hardware part, which includes the Arduino board, and the software part, which includes the Arduino IDE. The simplicity of Arduino has made it a popular component of many technical projects—but how can you make sure you’re choosing the right Arduino board for your project?
If you’re new to the world of Arduino development boards, an Arduino Uno R3 is your best option. With 14 digital pins and six analog pins, the Arduino Uno offers a total of 20 general-purpose input/output (GPIO) pins, which is sufficient for most beginner- and intermediate-level projects. The Arduino Uno also offers a pair of Rx and Tx pins, which are compatible with Serial Communications devices. Additionally, a separate pair of Rx and Tx pins can be integrated by including the header file SoftwareSerial.
The Uno R3 is available in two models: the normal version and SMD version. The SMD version features an Atmega328 controller IC and SMD chip soldered into the main board. Meanwhile, the normal version features solderless breadboard, with the IC held on by an IC holder. For beginners using the normal version of Uno, the IC can be replaced if it gets fried. However, if you use the SMD Uno, you may need to replace the board if you fry the IC.
Photo Credit: Unsplash
If you’re looking for a more affordable introduction to the world of Arduino, or if you need a smaller board, opt for the Arduino mini. The Mini offers the same functions at the Uno at a smaller size and cheaper price. With a length of about 3 cm, the Mini is suitable for smaller projects, such as small robots.
If your project requires extensive wiring, which requires more than 20 pins, an Arduino Mega is your best option. For example, if you’re working on a 5×5 LED Cube with 30 inputs, the Arduino Uno or Mini will be insufficient. In this case, you may opt to use a Decoder IC74595 to increase your inputs or invest in an Arduino Mega, which reduces the hassle of dealing with extra wires, PBCs, and ICs.
To further simplify your project, you may also opt for an Arduino Mega 2560, which has four pairs of Tx and Rx pins, allowing hobbyists to connect more serial communication devices if needed.
The Lilypad variant of the Aurdino board is typically used for Arduino projects embedded into clothing. The Arduino Lilypad is designed to be easily stitched onto different textiles and fabrics, with specially designed sensors and components on the main board. Additionally, a special conductive thread is used in place of connecting wires. If you’re working on a project and need to integrate an Arduino board into clothing, the Lilypad is your best option.
If you’re planning to connect your Arduino board to the Internet, a fast internet speed and reliable internet connection are essential. To find out a list of providers that serve your zip code, use the internet availability map by High Speed Internet Deals. While internet services providers may not serve the entire state, many listed service providers serve the select areas of the state. Rural areas are typically underserved, while larger urban and suburban areas receive the best coverage and a wide range of providers like Xfinity and Verizon. For more information on configuring your Arduino board as a web service, check out this tutorial.
With its huge flexibility and ability to be connected to modules like fire sensors, obstacle sensors, and GPS modules, hobbyists and makers can use Arduino boards to bring their dream projects to life.
